Introduction#
Centra is built to integrate with Enterprise Resource Planning systems. To facilitate this, Centra offers an API especially designed for the purpose, Centra's SOAP API. The API offers convenience functions to make it as easy as possible to integrate an ERP system. Unlike Centra's other JSON-based APIs this API uses an XML protocol, following the industry standard for ERP data exchange.
SOAP API introduction#
All operations and XML structures of the API are documented in SOAP API reference.
ID Conversion Table#
To make an integration as easy as possible to build and maintain, the SOAP API enables interactions with Centra based on IDs in the ERP system. This means the ERP system only has to be aware of its own IDs and not of Centra's IDs.
IDs and the ID conversion table is hence a fundamental part of this API.
The ids are always in the <id> tag in the XML, and are used to uniquely identify orders, products, customers and other data objects.
The ID conversion table translates back and forth between Centra’s internal IDs and the IDs you chose on your side.
When data originates from Centra; for example from orders, you will always get Centra’s internal numeric ID. For orders this is the order number.
When data originates from the ERP side, for example products, you can pick any unique <id> you prefer when you send the data to Centra. This is when the ID conversion table comes into effect; Centra will create a mapping from your ID to Centra’s internal numeric ID in the conversion table, and all data you see in the API will always use the ID you picked.
For example; you create a product with <id>yourProductId</id>. Once a product is created, you can update the product using that ID, and when you get an order from Centra containing that product, the XML data uses yourProductId for the product.
You can view and edit the conversion table in the Centra interface.
Communication#
Data transmission is always initiated by you. You request events to receive data from Centra, and you send updates to Centra when you want to modify data.
You will need to send a username and password with each request.
Events and the Event Queue#
When data that is relevant for the ERP integration changes in Centra, an event is created in the SOAP API.
You need to fetch events from Centra regularly, and for each event you fetch you need to tell Centra to remove it from the queue.
This is the only way data is sent from Centra to the ERP system.
Events are fetched using:
events_Get https://docs.centra.com/api-references/soap-integration-api/api-reference#events_Get
events_GetByMarkets https://docs.centra.com/api-references/soap-integration-api/api-reference#events_GetByMarkets (you can fetch events only for one or more markets)
Events are removed from the queue with events_Done
You need to use events_Done on all events, even if they are of an unknown type that you don’t handle. The API returns the oldest events, up to a 100 in each events_Get. If you do not use events_Done on all events, all 100 events will eventually be old and you won’t see any new events.
For example, if there are 234 events in the queue, events_Get will return the oldest 100. When you mark 10 of those as done with events_Done, they are removed from the queue. After that the queue will contain 224 events, events_Get will give you the 100 oldest again. This time 90 of those will be the same as the last time, 10 will be new.
The data for each event depends on the type of the event. Events of type “order” contain an order. The structure is the same as for the corresponding “update” operation for that type of data. An order event contains the data structure from orders_Update.
Each event contains the complete data for the object that has changed. It does not contain historical data, i.e., to know what has changed, you would need to compare it yourself to the data on your side to know that.
Updates#
The different update operations in the API will update or create new data objects in Centra. There are many different fields in the update operations, for example the products_Update. You do not need to send all fields, only the ones that are required to identify what object you want to update (the different <id> fields) and the fields with data that you want to change.
The fields that you do not include in the update are not changed.
If the data object you send does not exist in Centra, it will be created.
For example the customers_Update lets you update or create retail/B2C customers.
You need to send the <id> to identify what customer to update. If no customer with that ID exists, a new customer is created.
If you send the <firstname> but not the <lastname> for an existing customer, the <firstname> will be changed and the <lastname> will not be changed (it will not be set to blank).
Updates responses#
All updates return the same type of response. <success> can be true or false. If success is false, <errors> contains useful information why it failed. <notices> may contain additional information, both for successful and failed information.
1
2
3
4
5
6
<success>true</success>
<errors>
<notices>
<message>Example 1</message>
<message>Example 2</message>
</notices>1
2
3
4
5
<success>false</success>
<errors>
<message>Example 1</message>
</errors>
<notices/>Special characters and checkout fields limitations#
Depending on your ERP, there might be some limitations when it comes to the allowed types of characters, or to the allowed number of characters per field. Centra Admin backend will accept any characters set, and the fields lengths are designed to not be a limiting factor. If your ERP has known limits, e.g. allowing only 20 characters each for the customer's first and last name, you should make sure your front end partner is aware of this and ask them to introduce those limits in the checkout fields. Similarily, if your ERP only accepts ASCII characters, you would probably want to strip them in checkout, so that (for example) "Michael Ständer" is sent as "Michael Stander" into Centra.
API versions#
Version control is handled by adding new fields to the specification, rather than releasing new versions of the API, i.e., there i only one version in production at the same time. You will always be running that version.
If you are building a new integration, use the “SOAP API” endpoint. It looks like this: https://example.centra.com/ams/system/service/module/soap/api?wsdl
All examples in this documentation uses the “SOAP API” endpoint.
Cookbook#
Connection test#
To test the connection, use the events_Get operation. This is a read only operation, nothing bad can happen.
https://docs.centra.com/api-references/soap-integration-api/api-reference#events_Get
Information you need#
The API endpoint (and WSDL if you use the WSDL definition to build a client on your side)
Username
Password
The API endpoint typically looks something like this: http://example.centra.com/ams/system/service/module/soap/api
The WSDL definition is the API endpoint with ?wsdl at the end: http://example.centra.com/ams/system/service/module/soap/api?wsdl
1
2
3
4
5
6
7
8
9
10
11
12
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<events_GetRequest xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<type>all</type>
</events_GetRequest>
</soap:Body>
</soap:Envelope>1
2
3
4
5
6
7
8
<?xml version="1.0" encoding="UTF-8"?>
<SOAP-ENV:Envelope xmlns:SOAP-ENV="http://schemas.xmlsoap.org/soap/envelope/" xmlns:ns1="http://www.centra.com/webservices/">
<SOAP-ENV:Body>
<ns1:events_Get>
<ns1:events/>
</ns1:events_Get>
</SOAP-ENV:Body>
</SOAP-ENV:Envelope>Markets#
https://docs.centra.com/api-references/soap-integration-api/api-reference#markets_Update
Creates new, or updates existing markets in Centra.
As long as you are not working against a Centra instance that is used in production, this operation is simple and recommended to be a good one to start with.
The <id> you send to Centra will be used to refer to that market in the future. For example; an order placed in the market Retail-Global will have that market <id> on it when you fetch the order data from Centra. It is only used for the integration between the systems, so it does not need to be readable. The ID <id> is added to the ID conversion table.
The <description> is the name of the market in Centra’s admin interface. So this should be something administrators of the system can relate to.
Information you need#
IDs of the stores (1 and 2 in the example below) for
<store>Type of each store, either direct-to-consumer or wholesale for
<type>
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<markets_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<markets>
<market>
<id>Retail-Global</id>
<store>1</store>
<type>retail</type>
<description>Global</description>
</market>
<market>
<id>Retail-Sweden</id>
<store>1</store>
<type>retail</type>
<description>Sweden</description>
</market>
<market>
<id>Wholesale-Market</id>
<store>2</store>
<type>wholesale</type>
<description>Global</description>
</market>
</markets>
</markets_Update>
</soap:Body>
</soap:Envelope>1
2
3
4
5
6
7
8
9
10
<?xml version="1.0" encoding="UTF-8"?>
<SOAP-ENV:Envelope xmlns:SOAP-ENV="http://schemas.xmlsoap.org/soap/envelope/" xmlns:ns1="http://www.centra.com/webservices/">
<SOAP-ENV:Body>
<ns1:result>
<ns1:success>true</ns1:success>
<ns1:errors/>
<ns1:notices/>
</ns1:result>
</SOAP-ENV:Body>
</SOAP-ENV:Envelope>Product Data: Sizetables#
https://docs.centra.com/api-references/soap-integration-api/api-reference#sizes_Update
Before you can send product data to Centra you need to have size tables in place.
This example creates two sizetables:
One with sizes Small, Medium and Large. This will be used for a sweater in the next example.
One with a single unnamed size. This will be used for a chair later, a product that does not have different sizes.
Notice that a sizetable contains one or more sizes (the SML size table contains the sizes S, M, and L) but in the XML request this is the other way around: <sizetable> is inside the <size>.
On the <size> level, the <id> must be unique within that sizetable.
On the <sizetable> level, the <id> must be unique for all sizetables.
Notice that the size with <id> OS has a blank <description/>. This is useful for products that do not have different sizes. The size is never mentioned in the webshop or wholesale showroom.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<sizes_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<sizes>
<size>
<id>S</id>
<description>Small</description>
<sizetable>
<id>SML</id>
<description>Small Medium Large</description>
</sizetable>
</size>
<size>
<id>M</id>
<description>Medium</description>
<sizetable>
<id>SML</id>
<description>Small Medium Large</description>
</sizetable>
</size>
<size>
<id>L</id>
<description>Large</description>
<sizetable>
<id>SML</id>
<description>Small Medium Large</description>
</sizetable>
</size>
<size>
<id>OS</id>
<description/>
<sizetable>
<id>OneSize</id>
<description>One Size</description>
</sizetable>
</size>
</sizes>
</sizes_Update>
</soap:Body>
</soap:Envelope>The first time you send these sizetables, you will get some notices that new sizes are added.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
<?xml version="1.0" encoding="UTF-8"?>
<SOAP-ENV:Envelope xmlns:SOAP-ENV="http://schemas.xmlsoap.org/soap/envelope/" xmlns:ns1="http://www.centra.com/webservices/">
<SOAP-ENV:Body>
<ns1:result>
<ns1:success>true</ns1:success>
<ns1:errors/>
<ns1:notices>
<ns1:message>Added new size: S: Small to: Small Medium Large!</ns1:message>
<ns1:message>Added new size: M: Medium to: Small Medium Large!</ns1:message>
<ns1:message>Added new size: L: Large to: Small Medium Large!</ns1:message>
<ns1:message>Added new size: OS: to: One Size!</ns1:message>
</ns1:notices>
</ns1:result>
</SOAP-ENV:Body>
</SOAP-ENV:Envelope>When you send the same sizes_Update again, nothing changes in Centra and you will not get any notices in the response.
1
2
3
4
5
6
7
8
9
10
<?xml version="1.0" encoding="UTF-8"?>
<SOAP-ENV:Envelope xmlns:SOAP-ENV="http://schemas.xmlsoap.org/soap/envelope/" xmlns:ns1="http://www.centra.com/webservices/">
<SOAP-ENV:Body>
<ns1:result>
<ns1:success>true</ns1:success>
<ns1:errors/>
<ns1:notices/>
</ns1:result>
</SOAP-ENV:Body>
</SOAP-ENV:Envelope>Product Data: A Sweater example#
https://docs.centra.com/api-references/soap-integration-api/api-reference#products_Update
This example creates or updates a product – in this case a turtleneck sweater. It demonstrates Centra’s product structure of product, variants and sizes. The product comes in red and blue variants, and each variant is available in sizes S, M and L.
On the<product> level:
<id>must be unique across all products<status>is the products status. It can be inactive, active or canceled. Only active products are shown in a Centra store.<sku>see below<description>is the product’s name that people see in the Centra admin.<folder>is a way to organize products in the Centra admin (do not use an<id>for the folder). This is optional.<brand>is the product’s brand. The<id>is used only in the API, the<description>is the brand name displayed in the Admin and in the Centra stores.<collection>is the collection that this product is a part of. For example “Spring 2019”. This is optional.
On the <variation> level:
<id>must be unique across all variants, not just the variants connected to this product<stockid>use the same value as<id><sizetable>this is the sizetable that the variant has, and this determines what sizes it can have.The other fields have the same functions as those on the product level
On the <size> level:
<id>here is for a size id, connected to the sizetable.<ean>is the EAN code (or GTIN, UPC, barcode). Centra does not require this field itself, but if Centra connects to other systems it might be required.
The <sku> field is not required by Centra itself, but if Centra connects to other systems it might be required. The <product>, <variation> and <size> each contain a <sku> field. To form the SKU of a size, you concatenate the <sku> from the product, variation and size. In the example, the full SKU for the red sweater in size S is TURTLE001RED01.
Preconditions#
Sizetables must have been created in Centra
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<products_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<products>
<product>
<id>T001</id>
<status>active</status>
<sku>TURTLE001</sku>
<description>Turtleneck sweater</description>
<folder>
<description>Sweaters / Turtleneck</description>
</folder>
<brand>
<id>Example</id>
<description>Example Brand</description>
</brand>
<collection>
<id>XMAS</id>
<description>X-Mas</description>
</collection>
<variations>
<variation>
<id>T001_RED</id>
<stockid>T001_RED</stockid>
<description>Red</description>
<sku>RED</sku>
<status>active</status>
<sizetable>
<id>SML</id>
</sizetable>
<sizes>
<size>
<id>S</id>
<sku>01</sku>
<ean>1234567890123</ean>
</size>
<size>
<id>M</id>
<sku>02</sku>
<ean>1234567890124</ean>
</size>
<size>
<id>L</id>
<sku>03</sku>
<ean>1234567890125</ean>
</size>
</sizes>
</variation>
<variation>
<id>T001_BLUE</id>
<stockid>T001_BLUE</stockid>
<description>Blue</description>
<sku>BLUE</sku>
<status>inactive</status>
<sizetable>
<id>SML</id>
</sizetable>
<sizes>
<size>
<id>S</id>
<sku>01</sku>
<ean>2234567890123</ean>
</size>
<size>
<id>M</id>
<sku>02</sku>
<ean>2234567890124</ean>
</size>
<size>
<id>L</id>
<sku>03</sku>
<ean>2234567890125</ean>
</size>
</sizes>
</variation>
</variations>
</product>
</products>
</products_Update>
</soap:Body>
</soap:Envelope>1
2
3
4
5
6
7
8
9
10
<?xml version="1.0" encoding="UTF-8"?>
<SOAP-ENV:Envelope xmlns:SOAP-ENV="http://schemas.xmlsoap.org/soap/envelope/" xmlns:ns1="http://www.centra.com/webservices/">
<SOAP-ENV:Body>
<ns1:result>
<ns1:success>true</ns1:success>
<ns1:errors/>
<ns1:notices/>
</ns1:result>
</SOAP-ENV:Body>
</SOAP-ENV:Envelope>Product Data: A Chair example#
https://docs.centra.com/api-references/soap-integration-api/api-reference#products_Update
This example creates or updates a product. We will be using a chair for this example. The product does not have different variants or sizes. To fit Centra’s product structure, it is created with a single variant and a single size.
Notice that this example does not send a <sku> or <ean> as Centra does not require it. If you have SKU and EAN codes, do send them. This example illustrates that SKU/EAN are not required for the integration to work, which can be very useful when synchronizing data early on in a sales cycle.
Information you need#
Sizetables must have been created in Centra
All variant names must be unique within one product.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<products_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<products>
<product>
<id>PWC</id>
<status>active</status>
<description>Plain wood chair</description>
<folder>
<description>Furniture / Chairs</description>
</folder>
<brand>
<id>Example</id>
<description>Example Brand</description>
</brand>
<collection>
<id>XMAS</id>
<description>X-Mas</description>
</collection>
<variations>
<variation>
<id>PWC</id>
<stockid>PWC</stockid>
<description>Plain</description>
<status>active</status>
<sizetable>
<id>OneSize</id>
</sizetable>
<sizes>
<size>
<id>OS</id>
</size>
</sizes>
</variation>
</variations>
</product>
</products>
</products_Update>
</soap:Body>
</soap:Envelope>Product Data: Bundle product example#
Bundles behave like real products in terms of adding them to a selection, applying discounts and creating shipments. They do not exist in reality in the warehouse, but consist of multiple "real" products, which needs to be taken into consideration by the pick-and-pack staff.
Non-bundle products look exactly the same as they used to: they include SKU, quantity, specific variant and size, price, warehouse etc. For bundles (and bundled products) a new section called <bundleinfo> was introduced. For example, here's a snippet from an order including a bundle consisting of two actual products:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
<products>
<product>
<id>5910</id>
<sku>BP1</sku>
...
<qty>1</qty>
<description>Bundle Part 1</description>
<variation>
<id>7938</id>
<description>Test variation 1</description>
</variation>
<sizes>
<size>
<id>129</id>
<sku></sku>
<qty>1</qty>
<description>One Size</description>
<orderitem>
<id>2882</id>
</orderitem>
...
</size>
</sizes>
<comment></comment>
<bundleinfo>
<isbundle>false</isbundle>
<partof>
<product>
<id>5925</id>
</product>
</partof>
</bundleinfo>
</product>
<product>
<id>5927</id>
<sku>BP2</sku>
...
<qty>1</qty>
<description>Bundle Part 2</description>
<variation>
<id>7955</id>
<description>Test variation 2</description>
</variation>
<sizes>
<size>
<id>129</id>
<sku></sku>
<qty>1</qty>
<description>One Size</description>
<orderitem>
<id>2883</id>
</orderitem>
...
</size>
</sizes>
<comment></comment>
<bundleinfo>
<isbundle>false</isbundle>
<partof>
<product>
<id>5925</id>
</product>
</partof>
</bundleinfo>
</product>
<product>
<id>5925</id>
<sku>B-221</sku>
...
<qty>1</qty>
<subtotal>0</subtotal>
<description>Bundle 221</description>
<variation>
<id>7953</id>
<description></description>
</variation>
<sizes>
<size>
<id>129</id>
<sku></sku>
<qty>1</qty>
<description>One Size</description>
<orderitem>
<id>2884</id>
</orderitem>
...
</size>
</sizes>
<comment></comment>
<bundleinfo>
<isbundle>true</isbundle>
</bundleinfo>
</product>
</products>As you can see, of the 3 items two are a part of the bundle and the last one is the actual bundle product. This can be easily recognised by the tag <isbundle>true</isbundle> on product 5925. Two other products are not bundles, but parts of it - we call them "bundled products". You can see they are a part of bundle product 5925: <partof><product><id>5925</...>. This means that product 5925 (SKU: B-221) should be ignored by the pick-and-pack team, and the contents of the bundle should be collected by taking one of products 5910 (SKU: BP1) and 5927 (SKU: BP2) and packing them together.
To sum up, there are 3 types of products:
Standard, non-bundle products with no
<bundleinfo>tag,Virtual bundle product, recognised by
<isbundle>true</isbundle>- not a product in a warehouse, but a collection of bundled products,Bundled product - part of a bundle - tagged
<isbundle>false</isbundle>and including the ID of the parent bundle product. These are the real warehouse products that need to be picked and packed as part of the order.
Product Stock: Warehouses#
https://docs.centra.com/api-references/soap-integration-api/api-reference#warehouses_Update
Creates or updates warehouses in Centra.
This operation is optional. If you simply send stock numbers to a warehouse <id> in the next example without creating warehouses first, the warehouses will be created automatically.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<warehouses_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<warehouses>
<warehouse>
<id>MainWarehouse</id>
<description>Main Warehouse</description>
</warehouse>
<warehouse>
<id>OtherWarehouse</id>
<description>Other Warehouse</description>
</warehouse>
</warehouses>
</warehouses_Update>
</soap:Body>
</soap:Envelope>Product Stock: Stock Update#
https://docs.centra.com/api-references/soap-integration-api/api-reference#products_Update
Set product stock quantities in a warehouse.
This uses the same products_Update operation as the “Product Data”, but with fewer and different fields. It changes the stock quantities of the Chair from “Product Data 3 - A Chair”.
On the <product>, <variation> and <size> the different IDs remain from the “Product Data 3 - A Chair” example. These are required to identify what sizes to change.
The <warehouseitems> is new in this example, this sets the stock quantities of that size in two different warehouses
The stock <qty> is the number of items that are available for sale that has not been reserved for existing orders. It is not the number of items on the shelf in the warehouse.
In Centra this is called FTA – free to allocate.
When an order is placed in Centra it will allocate (reserve) stock, reducing the FTA. The number on the shelf stays the same. After an order has shipped, the number on the shelf is reduced.
You need to send the number of items on the shelf in the warehouse minus what is reserved for unshipped orders in Centra or elsewhere.
This also means you should fetch orders from Centra before sending stock updates to be able to calculate the correct stock values. (See the order examples)
Preconditions#
The products must exist in Centra
All variant names must be unique within one product.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<products_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<products>
<product>
<id>PWC</id>
<variations>
<variation>
<id>PWC</id>
<stockid>PWC</stockid>
<sizes>
<size>
<id>OS</id>
<warehouseitems>
<warehouse>
<id>MainWarehouse</id>
<qty>1</qty>
</warehouse>
<warehouse>
<id>OtherWarehouse</id>
<qty>2</qty>
</warehouse>
</warehouseitems>
</size>
</sizes>
</variation>
</variations>
</product>
</products>
</products_Update>
</soap:Body>
</soap:Envelope>Pricelists#
https://docs.centra.com/api-references/soap-integration-api/api-reference#pricelists_Update
Update or create pricelists. A pricelist contains prices for products in a specific currency.
This example creates two pricelists. One for a direct-to-consumer store and one for a wholesale store. You can have multiple pricelists in each store, and even multiple pricelists in the same store with the same currency.
Prices in Centra can be set at the product or variant level, but not on the size level.
Information you need#
IDs of the stores (1 and 2 in the example below). Contact Centra directly to get provided with the correct IDs.
Currencies in Centra matching the
<currency>you send in the XML. Currencies are configured manually in Centra.
Preconditions#
Products must exist in Centra. See the product examples.
Fields#
On the <pricelist> level:
<id>is the unique ID of the pricelist<description>is the name visible in the Centra admin<store>and<type>connects the pricelist to a store<currency>is the name of the currency in Centra.
On the <item> level
<id>is the product ID (See the product examples)
On the <variation> level
<id>is the variation ID (See the product examples)All variant names must be unique within one product
Notice that the wholesale prices have a <priceb> field. This is the recommended retail price. It is optional, and only used for wholesale.
Also note that the T001 product has prices on the variant level (the blue one is more expensive than the red one). The PWC product has prices on the product level, so if it had multiple variants they would have the same price.
When using Time Altered Prices you can use two new properties set on item and variation levels. <alteredprice> and <alteredpriceb> will set the Time Altered Prices for given product or variant. Example was presented on T001.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<pricelists_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<pricelists>
<pricelist>
<id>EUR-Retail</id>
<store>1</store>
<type>retail</type>
<currency>EUR</currency>
<description>Euro</description>
<items>
<product>
<id>T001</id>
<variation>
<id>T001_RED</id>
<price>123</price>
</variation>
<variation>
<id>T001_BLUE</id>
<price>234</price>
</variation>
</product>
<product>
<id>PWC</id>
<price>1000</price>
</product>
</items>
</pricelist>
<pricelist>
<id>USD-Wholesale</id>
<store>2</store>
<type>wholesale</type>
<currency>USD</currency>
<description>US Dollar</description>
<items>
<product>
<id>T001</id>
<variation>
<id>T001_RED</id>
<price>45</price>
<priceb>123</priceb>
<alteredprice>50</alteredprice>
<alteredpriceb>150</alteredpriceb>
</variation>
<variation>
<id>T001_BLUE</id>
<price>67</price>
<priceb>234</priceb>
<alteredprice>80</alteredprice>
<alteredpriceb>250</alteredpriceb>
</variation>
</product>
<product>
<id>PWC</id>
<price>700</price>
<priceb>1000</priceb>
</product>
</items>
</pricelist>
</pricelists>
</pricelists_Update>
</soap:Body>
</soap:Envelope>Time Alteration Dates#
https://docs.centra.com/soap/index.php?op=timealterationdates_Update
Create or update Time Alteration Dates. To use Time Altered Prices you need to have an active Time Alteration Date first. You can read more about Time Altered Prices here.
Notice that this functionality works only on Wholesale stores.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<pricealterationdates_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>????</password>
</login>
<pricealterationdates>
<pricealterationdate>
<id>H20</id>
<status>active</status>
<name>Halloween 2020</name>
<store>1</store>
<startdate>2020-11-30</startdate>
</pricealterationdate>
</pricealterationdates>
</pricealterationdates_Update>
</soap:Body>
</soap:Envelope>Wholesale Accounts: Payment Terms#
https://docs.centra.com/soap/index.php?op=paymentterms_Update
Create or update payment terms. The payment terms are set on an account, so they should be created before the account data is sent to Centra.
Notice that <name> is the name or title of the payment term in the Centra admin, the <description> is a longer optional descriptive text. This is different form other data in the API where <description> is the name or title of something.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<paymentterms_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<paymentterms>
<paymentterms>
<id>30NET</id>
<name>30 Days</name>
<description>Optional text describing this paymentterm</description>
<duedays>30</duedays>
</paymentterms>
</paymentterms>
</paymentterms_Update>
</soap:Body>
</soap:Envelope>Wholesale Accounts: Shipping Terms#
https://docs.centra.com/soap/index.php?op=shippingterms_Update
Create or update shipping terms. The shipping terms are set on an account, so they should be created before the account data is sent to Centra.
Notice that <name> is the name or title of the shipping term in the Centra admin. The <description> is a longer optional descriptive text. This is different form other data in the API where <description> is the name or title of something.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<shippingterms_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<shippingterms>
<shippingterms>
<id>DDU</id>
<name>Delivered Duty Unpaid</name>
<description>Optional text describing this shippingterm</description>
</shippingterms>
</shippingterms>
</shippingterms_Update>
</soap:Body>
</soap:Envelope>Wholesale Accounts: Account Data#
https://docs.centra.com/soap/index.php?op=accounts_Update
Creates or updates an account. The account is the data for a wholesale customer, a company that can make purchases in Centra Showroom or by entering or importing orders manually.
Information you need#
Store IDs of the wholesale store or stores. Contact us and we will provide them to you.
Preconditions#
Pricelists should exist
Markets should exist
Payment and shipping terms should exist if you send the optional
<paymentterms>or<shippingterms>
Fields#
<status>can be active, inactive or canceled. Only active accounts can make purchases<accountaddress>is the visiting address<buyers>is a list of one or more buyers. They are users that can log into the wholesale showroom and make purchases for the account.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<accounts_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<accounts>
<account>
<id>12345</id>
<type>wholesale</type>
<status>active</status>
<description>Company Name</description>
<market>
<id>Wholesale-Market</id>
</market>
<pricelist>
<id>USD-Wholesale</id>
</pricelist>
<paymentterms>
<id>30NET</id>
</paymentterms>
<shippingterms>
<id>DDU</id>
</shippingterms>
<accountaddress>
<company>Example</company>
<attn>Person name</attn>
<address1>Street 1</address1>
<address2>Suite 123</address2>
<city>City</city>
<state>State</state>
<zipcode>12345</zipcode>
<country>US</country>
<email>info@example.com</email>
<telephone>123 456 789</telephone>
<url>www.example.com</url>
</accountaddress>
<shippingaddress>
<company>Example Warehouse</company>
<attn>Person name</attn>
<address1>Street 1</address1>
<address2>Suite 123</address2>
<city>City</city>
<state>State</state>
<zipcode>12345</zipcode>
<country>FR</country>
<email>info@example.com</email>
<telephone>123 456 789</telephone>
</shippingaddress>
<invoiceaddress>
<company>Example Billing</company>
<attn>Person name</attn>
<address1>Street 1</address1>
<address2>Suite 123</address2>
<city>City</city>
<state></state>
<zipcode>12345</zipcode>
<country>SE</country>
<email>info@example.com</email>
<telephone>123 456 789</telephone>
<vat>SE12345678901</vat>
</invoiceaddress>
<buyers>
<buyer>
<id>12345_buyer1</id>
<store>2</store>
<status>active</status>
<firstname>Frist</firstname>
<lastname>Last</lastname>
<email>first.last@example.com</email>
</buyer>
</buyers>
</account>
</accounts>
</accounts_Update>
</soap:Body>
</soap:Envelope>Direct-to-Consumer orders: Event#
https://docs.centra.com/soap/index.php?op=events_Get
This example uses the events_Get operation to get order events. The response contains an order from the direct-to-consumer store, and examples after this one will update the order.
Notice that order has a <shipment> on it. Sometimes Centra is configured to automatically create shipments for direct-to-consumer orders. It can also be configured to not do that. In that case you would need to create the shipment. (This is illustrated in the wholesale order examples.)
Request#
<type>limits the type of events you get. Using all will return all types.
1
2
3
4
5
6
7
8
9
10
11
12
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<events_GetRequest xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<type>order</type>
</events_GetRequest>
</soap:Body>
</soap:Envelope>Response#
On the <event> level:
<id>is the ID of the event itself. This is needed for the events_Done operation, the next example.<type>is the event type, the type of data inside<data>
On the <order> level:
This data is the same as the data you can send to the https://docs.centra.com/soap/index.php?op=orders_Update
<id>is the Centra order number, or the converted ID that was used when inserting or updating the order<ordernumber>is always the Centra order number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
<?xml version="1.0" encoding="UTF-8"?>
<SOAP-ENV:Envelope xmlns:SOAP-ENV="http://schemas.xmlsoap.org/soap/envelope/" xmlns:ns1="http://www.centra.com/webservices/">
<SOAP-ENV:Body>
<ns1:events_Get>
<ns1:events>
<ns1:event>
<ns1:id>115</ns1:id>
<ns1:type>order</ns1:type>
<ns1:entry>30</ns1:entry>
<ns1:mission>update</ns1:mission>
<ns1:date>2019-03-27 12:52:20</ns1:date>
<ns1:data>
<ns1:order>
<ns1:id>30</ns1:id>
<ns1:ordernumber>30</ns1:id>
<ns1:type>retail</ns1:type>
<ns1:store>1</ns1:store>
<ns1:status>processing</ns1:status>
<ns1:ordertotal>1135.00</ns1:ordertotal>
<ns1:currency>EUR</ns1:currency>
<ns1:currencyrate>10.43100</ns1:currencyrate>
<ns1:basecurrency>SEK</ns1:basecurrency>
<ns1:created>2019-03-27T12:52:20+01:00</ns1:created>
<ns1:internal>false</ns1:internal>
<ns1:preferred_shipping_date/>
<ns1:collection>
<ns1:id>XMAS</ns1:id>
<ns1:description>X-Mas</ns1:description>
</ns1:collection>
<ns1:primary_warehouse>
<ns1:warehouse>
<ns1:id>CW</ns1:id>
</ns1:warehouse>
</ns1:primary_warehouse>
<ns1:shipping>
<ns1:subtotal>12</ns1:subtotal>
<ns1:description>Sweden</ns1:description>
<ns1:key>eur</ns1:key>
</ns1:shipping>
<ns1:payments>
<ns1:name>dibs-window</ns1:name>
<ns1:type>cc</ns1:type>
<ns1:total>0</ns1:total>
<ns1:status>incomplete</ns1:status>
<ns1:method>test</ns1:method>
<ns1:payment>
<ns1:type>auth</ns1:type>
<ns1:value>1135</ns1:value>
<ns1:created>2019-03-27T12:52:20+01:00</ns1:created>
<ns1:transaction>2404544843</ns1:transaction>
</ns1:payment>
</ns1:payments>
<ns1:products>
<ns1:product>
<ns1:id>PWC</ns1:id>
<ns1:tax>25.000</ns1:tax>
<ns1:sku/>
<ns1:origprice>1000.00</ns1:origprice>
<ns1:price>1000.00</ns1:price>
<ns1:discount>0</ns1:discount>
<ns1:qty>1</ns1:qty>
<ns1:subtotal>1000</ns1:subtotal>
<ns1:description>Plain wood chair</ns1:description>
<ns1:variation>
<ns1:id>PWC</ns1:id>
<ns1:description>Plain</ns1:description>
</ns1:variation>
<ns1:brand>
<ns1:id>Example</ns1:id>
<ns1:description>Example Brand</ns1:description>
</ns1:brand>
<ns1:sizes>
<ns1:size>
<ns1:id>OS</ns1:id>
<ns1:sku/>
<ns1:qty>1</ns1:qty>
<ns1:preorder>no</ns1:preorder>
<ns1:description/>
<ns1:orderitem>
<ns1:id>80</ns1:id>
</ns1:orderitem>
<ns1:warehouseitems>
<ns1:warehouse>
<ns1:id>OtherWarehouse</ns1:id>
<ns1:qty>1</ns1:qty>
</ns1:warehouse>
</ns1:warehouseitems>
<ns1:supplierorderitems/>
</ns1:size>
</ns1:sizes>
<ns1:comment/>
</ns1:product>
<ns1:product>
<ns1:id>T001</ns1:id>
<ns1:tax>25.000</ns1:tax>
<ns1:sku>TURTLE001</ns1:sku>
<ns1:origprice>123.00</ns1:origprice>
<ns1:price>123.00</ns1:price>
<ns1:discount>0</ns1:discount>
<ns1:qty>1</ns1:qty>
<ns1:subtotal>123</ns1:subtotal>
<ns1:description>Turtleneck sweater</ns1:description>
<ns1:variation>
<ns1:id>T001_RED</ns1:id>
<ns1:description>Red</ns1:description>
</ns1:variation>
<ns1:brand>
<ns1:id>Example</ns1:id>
<ns1:description>Example Brand</ns1:description>
</ns1:brand>
<ns1:sizes>
<ns1:size>
<ns1:id>S</ns1:id>
<ns1:sku>01</ns1:sku>
<ns1:qty>1</ns1:qty>
<ns1:preorder>no</ns1:preorder>
<ns1:description>Small</ns1:description>
<ns1:orderitem>
<ns1:id>81</ns1:id>
</ns1:orderitem>
<ns1:warehouseitems>
<ns1:warehouse>
<ns1:id>MainWarehouse</ns1:id>
<ns1:qty>1</ns1:qty>
</ns1:warehouse>
</ns1:warehouseitems>
<ns1:supplierorderitems/>
</ns1:size>
</ns1:sizes>
<ns1:comment/>
</ns1:product>
</ns1:products>
<ns1:cancelled/>
<ns1:shipments>
<ns1:shipment>
<ns1:id>8</ns1:id>
<ns1:paid>no</ns1:paid>
<ns1:shipped>no</ns1:shipped>
<ns1:goodtogo>yes</ns1:goodtogo>
<ns1:appendix>1</ns1:appendix>
<ns1:shipmenttotal>1135.00</ns1:shipmenttotal>
<ns1:paidtotal>0.00</ns1:paidtotal>
<ns1:currency>EUR</ns1:currency>
<ns1:currencyrate>10.43100</ns1:currencyrate>
<ns1:basecurrency>SEK</ns1:basecurrency>
<ns1:created>2019-03-27T12:52:20+01:00</ns1:created>
<ns1:shippingaddress>
<ns1:firstname>Example</ns1:firstname>
<ns1:lastname>Person</ns1:lastname>
<ns1:address1>Teststreet 123</ns1:address1>
<ns1:address2/>
<ns1:city>Testcity</ns1:city>
<ns1:state/>
<ns1:zipcode>12345</ns1:zipcode>
<ns1:country>SE</ns1:country>
<ns1:email>someone@example.com</ns1:email>
<ns1:telephone>123456789</ns1:telephone>
</ns1:shippingaddress>
<ns1:carrierinformation>
<ns1:carrier/>
<ns1:service/>
<ns1:tracking/>
<ns1:packages>0</ns1:packages>
</ns1:carrierinformation>
<ns1:products>
<ns1:product>
<ns1:id>PWC</ns1:id>
<ns1:tax>25.000</ns1:tax>
<ns1:sku/>
<ns1:origprice>1000.00</ns1:origprice>
<ns1:price>1000.00</ns1:price>
<ns1:discount>0</ns1:discount>
<ns1:qty>1</ns1:qty>
<ns1:subtotal>1000</ns1:subtotal>
<ns1:description>Plain wood chair</ns1:description>
<ns1:variation>
<ns1:id>PWC</ns1:id>
<ns1:description>Plain</ns1:description>
</ns1:variation>
<ns1:brand>
<ns1:id>Example</ns1:id>
<ns1:description>Example Brand</ns1:description>
</ns1:brand>
<ns1:sizes>
<ns1:size>
<ns1:id>OS</ns1:id>
<ns1:sku/>
<ns1:qty>1</ns1:qty>
<ns1:preorder>no</ns1:preorder>
<ns1:description/>
<ns1:orderitem>
<ns1:id>80</ns1:id>
</ns1:orderitem>
</ns1:size>
</ns1:sizes>
<ns1:comment/>
</ns1:product>
<ns1:product>
<ns1:id>T001</ns1:id>
<ns1:tax>25.000</ns1:tax>
<ns1:sku>TURTLE001</ns1:sku>
<ns1:origprice>123.00</ns1:origprice>
<ns1:price>123.00</ns1:price>
<ns1:discount>0</ns1:discount>
<ns1:qty>1</ns1:qty>
<ns1:subtotal>123</ns1:subtotal>
<ns1:description>Turtleneck sweater</ns1:description>
<ns1:variation>
<ns1:id>T001_RED</ns1:id>
<ns1:description>Red</ns1:description>
</ns1:variation>
<ns1:brand>
<ns1:id>Example</ns1:id>
<ns1:description>Example Brand</ns1:description>
</ns1:brand>
<ns1:sizes>
<ns1:size>
<ns1:id>S</ns1:id>
<ns1:sku>01</ns1:sku>
<ns1:qty>1</ns1:qty>
<ns1:preorder>no</ns1:preorder>
<ns1:description>Small</ns1:description>
<ns1:orderitem>
<ns1:id>81</ns1:id>
</ns1:orderitem>
</ns1:size>
</ns1:sizes>
<ns1:comment/>
</ns1:product>
</ns1:products>
<ns1:refunds/>
<ns1:shipping>
<ns1:subtotal>12</ns1:subtotal>
</ns1:shipping>
<ns1:handling>
<ns1:subtotal>0.00</ns1:subtotal>
</ns1:handling>
<ns1:voucher>
<ns1:subtotal>0</ns1:subtotal>
</ns1:voucher>
</ns1:shipment>
</ns1:shipments>
<ns1:carrierinformation>
<ns1:carrier/>
<ns1:service/>
<ns1:account/>
<ns1:taxid/>
</ns1:carrierinformation>
<ns1:customer>
<ns1:id>20</ns1:id>
</ns1:customer>
<ns1:shippingaddress>
<ns1:firstname>Example</ns1:firstname>
<ns1:lastname>Person</ns1:lastname>
<ns1:address1>Teststreet 123</ns1:address1>
<ns1:address2/>
<ns1:city>Testcity</ns1:city>
<ns1:state/>
<ns1:zipcode>12345</ns1:zipcode>
<ns1:country>SE</ns1:country>
<ns1:email>someone@example.com</ns1:email>
<ns1:telephone>123456789</ns1:telephone>
</ns1:shippingaddress>
<ns1:billingaddress>
<ns1:firstname>Example</ns1:firstname>
<ns1:lastname>Person</ns1:lastname>
<ns1:address1>Teststreet 123</ns1:address1>
<ns1:address2/>
<ns1:city>Testcity</ns1:city>
<ns1:state/>
<ns1:zipcode>12345</ns1:zipcode>
<ns1:country>SE</ns1:country>
<ns1:email>someone@example.com</ns1:email>
<ns1:telephone>123456789</ns1:telephone>
</ns1:billingaddress>
<ns1:internalinformation/>
<ns1:other/>
<ns1:market>
<ns1:id>Retail-Sweden</ns1:id>
<ns1:description>Sweden</ns1:description>
</ns1:market>
<ns1:pricelist>
<ns1:id>EUR-Retail</ns1:id>
<ns1:description>Euro</ns1:description>
</ns1:pricelist>
</ns1:order>
</ns1:data>
</ns1:event>
</ns1:events>
</ns1:events_Get>
</SOAP-ENV:Body>
</SOAP-ENV:Envelope>Optional Ingrid data
If you're using Ingrid to show advanced shipping options in your checkout, after the Order is finalized you will see the Ingrid data under the order level, under the <additionals> tag. For example:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
<ns1:additionals>
<ns1:additional>
<ns1:key>shipwallet_deliverytime</ns1:key>
<ns1:value>YYYY-MM-DD</ns1:value>
</ns1:additional>
<ns1:additional>
<ns1:key>shipwallet_doorcode</ns1:key>
<ns1:value>XXXX</ns1:value>
</ns1:additional>
<ns1:additional>
<ns1:key>shipwallet_id</ns1:key>
<ns1:value>abcdef1234567890abcdef1234567890</ns1:value>
</ns1:additional>
<ns1:additional>
<ns1:key>shipwallet_method</ns1:key>
<ns1:value>pnl-mpc</ns1:value>
</ns1:additional>
<ns1:additional>
<ns1:key>shipwallet_pickup</ns1:key>
<ns1:value/>
</ns1:additional>
<ns1:additional>
<ns1:key>shipwallet_courier_instructions</ns1:key>
<ns1:value/>
</ns1:additional>
</ns1:additionals>Direct-to-Consumer orders: Event Done#
https://docs.centra.com/soap/index.php?op=events_Done
This marks the event from the previous example as done. That event had ID 115. To illustrate how to mark multiple events as done at the same time, this example also sends event IDs 116 and 117.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<events_Done xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<event>115</event>
<event>116</event>
<event>117</event>
</events_Done>
</soap:Body>
</soap:Envelope>Direct-to-consumer orders: Lock Order#
https://docs.centra.com/soap/index.php?op=orders_Update
Locking an order prevents most changes to the order in the Centra admin. This is a good idea if your side takes ownership of the order data after you have imported the order.
This orders_Update will only change the <locked> status. Nothing else on the order is changed.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<orders_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<orders>
<order>
<id>30</id>
<type>retail</type>
<store>1</store>
<locked>yes</locked>
</order>
</orders>
</orders_Update>
</soap:Body>
</soap:Envelope>Direct-to-Consumer orders: Order Shipped#
https://docs.centra.com/soap/index.php?op=orders_Update
This marks the shipment of the order as shipped, and sets the tracking number for the shipment.
Important: Capture#
The <capture>yes</capture> will instruct Centra to capture the payment for the shipment with the payment provider, to actually withdraw the money from the customer’s account.
In most cases direct-to-consumer orders will only reserve the payment until the order is shipped. When the order is shipped the payment must be “captured”.
The <capture>yes</capture> will capture if it’s possible to perform a capture on this order. If its not possible or the order has already been captured it has no effect. This makes it possible for you to always send <capture>yes</capture> when a shipment has been shipped without having to figure out if this order has already been captured.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<orders_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<orders>
<order>
<id>30</id>
<type>retail</type>
<store>1</store>
<status>completed</status>
<shipments>
<shipment>
<id>8</id>
<shipped>yes</shipped>
<capture>yes</capture>
<carrierinformation>
<carrier>UPS</carrier>
<service>STANDARD</service>
<tracking>1Z123123123123</tracking>
</carrierinformation>
</shipment>
</shipments>
</order>
</orders>
</orders_Update>
</soap:Body>
</soap:Envelope>Direct-to-Consumer orders: Create Return (Refund)#
https://docs.centra.com/soap/index.php?op=orders_Update
Create the return of the shipment and refund previously purchased items.
Important: Return ID#
Return IDs are not based on Order IDs, like shipment IDs are. The <id>12</id> under <refund>needs to be globally unique.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<orders_Update>
<login>
<username>example</username>
<password>???</password>
</login>
<orders>
<order>
<id>30</id>
<type>retail</type>
<store>1</store>
<shipments>
<shipment>
<id>30-1</id>
<appendix>1</appendix>
<refunds>
<refund>
<id>12</id>
<status>confirmed</status>
<products>
<product>
<id>T001</id>
<variation>
<id>T001_RED</id>
</variation>
<sizes>
<size>
<id>S</id>
<qty>1</qty>
</size>
</sizes>
</product>
</products>
</refund>
</refunds>
</shipment>
</shipments>
</order>
</orders>
</orders_Update>
</soap:Body>
</soap:Envelope>Wholesale orders: Event By Markets#
https://docs.centra.com/soap/index.php?op=events_GetByMarkets
This example uses the events_GetByMarkets operation to get order events from a specific market. The response contains an order from the wholesale store, and examples after this one will update the order.
Compared to the direct-to-consumer order event example, this uses events_GetByMarkets only to show an example of how it’s used. You could use events_Get instead, and get order events from all markets.
Also compared to the direct-to-consumer order, this order does not have any shipment on it.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<events_GetByMarkets xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<type>order</type>
<markets>
<market>
<id>Wholesale-Market</id>
</market>
</markets>
</events_GetByMarkets>
</soap:Body>
</soap:Envelope>1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
<?xml version="1.0" encoding="UTF-8"?>
<SOAP-ENV:Envelope xmlns:SOAP-ENV="http://schemas.xmlsoap.org/soap/envelope/" xmlns:ns1="http://www.centra.com/webservices/">
<SOAP-ENV:Body>
<ns1:events_Get>
<ns1:events>
<ns1:event>
<ns1:id>121</ns1:id>
<ns1:type>order</ns1:type>
<ns1:entry>25</ns1:entry>
<ns1:mission>update</ns1:mission>
<ns1:date>2019-03-27 13:45:44</ns1:date>
<ns1:data>
<ns1:order>
<ns1:id>25</ns1:id>
<ns1:type>wholesale</ns1:type>
<ns1:store>2</ns1:store>
<ns1:status>pending</ns1:status>
<ns1:currency>USD</ns1:currency>
<ns1:currencyrate>9.18707</ns1:currencyrate>
<ns1:basecurrency>SEK</ns1:basecurrency>
<ns1:created>2019-03-26T18:32:35+01:00</ns1:created>
<ns1:internal>false</ns1:internal>
<ns1:preferred_shipping_date/>
<ns1:buyer>
<ns1:id>12345_buyer1</ns1:id>
<ns1:firstname>Frist</ns1:firstname>
<ns1:lastname>Last</ns1:lastname>
<ns1:email>first.last@example.com</ns1:email>
</ns1:buyer>
<ns1:salesrep/>
<ns1:account>
<ns1:id>12345</ns1:id>
</ns1:account>
<ns1:paymentterms>
<ns1:id>30NET</ns1:id>
<ns1:description>30 Days</ns1:description>
</ns1:paymentterms>
<ns1:shippingterms>
<ns1:id>DDU</ns1:id>
<ns1:description>Delivered Duty Unpaid</ns1:description>
</ns1:shippingterms>
<ns1:collection>
<ns1:id>XMAS</ns1:id>
<ns1:description>X-Mas</ns1:description>
</ns1:collection>
<ns1:primary_warehouse>
<ns1:warehouse>
<ns1:id>CW</ns1:id>
</ns1:warehouse>
</ns1:primary_warehouse>
<ns1:shipping>
<ns1:subtotal>123</ns1:subtotal>
<ns1:description>France</ns1:description>
<ns1:key/>
</ns1:shipping>
<ns1:payments>
<ns1:type>inv</ns1:type>
<ns1:total>0</ns1:total>
<ns1:status>incomplete</ns1:status>
<ns1:method/>
</ns1:payments>
<ns1:products>
<ns1:product>
<ns1:id>PWC</ns1:id>
<ns1:tax>0.000</ns1:tax>
<ns1:sku/>
<ns1:origprice>700.00</ns1:origprice>
<ns1:price>700.00</ns1:price>
<ns1:discount>0</ns1:discount>
<ns1:qty>2</ns1:qty>
<ns1:subtotal>1400</ns1:subtotal>
<ns1:description>Plain wood chair</ns1:description>
<ns1:variation>
<ns1:id>PWC</ns1:id>
<ns1:description>Plain</ns1:description>
</ns1:variation>
<ns1:brand>
<ns1:id>Example</ns1:id>
<ns1:description>Example Brand</ns1:description>
</ns1:brand>
<ns1:sizes>
<ns1:size>
<ns1:id>OS</ns1:id>
<ns1:sku/>
<ns1:qty>2</ns1:qty>
<ns1:preorder>no</ns1:preorder>
<ns1:description/>
<ns1:orderitem>
<ns1:id>67</ns1:id>
</ns1:orderitem>
<ns1:warehouseitems>
<ns1:warehouse>
<ns1:id>OtherWarehouse</ns1:id>
<ns1:qty>2</ns1:qty>
</ns1:warehouse>
</ns1:warehouseitems>
<ns1:supplierorderitems/>
</ns1:size>
</ns1:sizes>
<ns1:comment/>
</ns1:product>
<ns1:product>
<ns1:id>T001</ns1:id>
<ns1:tax>0.000</ns1:tax>
<ns1:sku>TURTLE001</ns1:sku>
<ns1:origprice>67.00</ns1:origprice>
<ns1:price>67.00</ns1:price>
<ns1:discount>0</ns1:discount>
<ns1:qty>3</ns1:qty>
<ns1:subtotal>201</ns1:subtotal>
<ns1:description>Turtleneck sweater</ns1:description>
<ns1:variation>
<ns1:id>T001_BLUE</ns1:id>
<ns1:description>Blue</ns1:description>
</ns1:variation>
<ns1:brand>
<ns1:id>Example</ns1:id>
<ns1:description>Example Brand</ns1:description>
</ns1:brand>
<ns1:sizes>
<ns1:size>
<ns1:id>S</ns1:id>
<ns1:sku>01</ns1:sku>
<ns1:qty>1</ns1:qty>
<ns1:preorder>no</ns1:preorder>
<ns1:description>Small</ns1:description>
<ns1:orderitem>
<ns1:id>68</ns1:id>
</ns1:orderitem>
<ns1:warehouseitems>
<ns1:warehouse>
<ns1:id>MainWarehouse</ns1:id>
<ns1:qty>1</ns1:qty>
</ns1:warehouse>
</ns1:warehouseitems>
<ns1:supplierorderitems/>
</ns1:size>
<ns1:size>
<ns1:id>M</ns1:id>
<ns1:sku>02</ns1:sku>
<ns1:qty>2</ns1:qty>
<ns1:preorder>no</ns1:preorder>
<ns1:description>Medium</ns1:description>
<ns1:orderitem>
<ns1:id>69</ns1:id>
</ns1:orderitem>
<ns1:warehouseitems>
<ns1:warehouse>
<ns1:id>MainWarehouse</ns1:id>
<ns1:qty>2</ns1:qty>
</ns1:warehouse>
</ns1:warehouseitems>
<ns1:supplierorderitems/>
</ns1:size>
</ns1:sizes>
<ns1:comment/>
</ns1:product>
<ns1:product>
<ns1:id>T001</ns1:id>
<ns1:tax>0.000</ns1:tax>
<ns1:sku>TURTLE001</ns1:sku>
<ns1:origprice>45.00</ns1:origprice>
<ns1:price>45.00</ns1:price>
<ns1:discount>0</ns1:discount>
<ns1:qty>7</ns1:qty>
<ns1:subtotal>315</ns1:subtotal>
<ns1:description>Turtleneck sweater</ns1:description>
<ns1:variation>
<ns1:id>T001_RED</ns1:id>
<ns1:description>Red</ns1:description>
</ns1:variation>
<ns1:brand>
<ns1:id>Example</ns1:id>
<ns1:description>Example Brand</ns1:description>
</ns1:brand>
<ns1:sizes>
<ns1:size>
<ns1:id>M</ns1:id>
<ns1:sku>02</ns1:sku>
<ns1:qty>3</ns1:qty>
<ns1:preorder>no</ns1:preorder>
<ns1:description>Medium</ns1:description>
<ns1:orderitem>
<ns1:id>70</ns1:id>
</ns1:orderitem>
<ns1:warehouseitems>
<ns1:warehouse>
<ns1:id>MainWarehouse</ns1:id>
<ns1:qty>3</ns1:qty>
</ns1:warehouse>
</ns1:warehouseitems>
<ns1:supplierorderitems/>
</ns1:size>
<ns1:size>
<ns1:id>L</ns1:id>
<ns1:sku>03</ns1:sku>
<ns1:qty>4</ns1:qty>
<ns1:preorder>no</ns1:preorder>
<ns1:description>Large</ns1:description>
<ns1:orderitem>
<ns1:id>71</ns1:id>
</ns1:orderitem>
<ns1:warehouseitems>
<ns1:warehouse>
<ns1:id>MainWarehouse</ns1:id>
<ns1:qty>4</ns1:qty>
</ns1:warehouse>
</ns1:warehouseitems>
<ns1:supplierorderitems/>
</ns1:size>
</ns1:sizes>
<ns1:comment/>
</ns1:product>
</ns1:products>
<ns1:cancelled/>
<ns1:shipments/>
<ns1:carrierinformation>
<ns1:carrier/>
<ns1:service/>
<ns1:account/>
<ns1:taxid/>
</ns1:carrierinformation>
<ns1:shippingaddress>
<ns1:company>Example Warehouse</ns1:company>
<ns1:attn>Person name</ns1:attn>
<ns1:address1>Street 1</ns1:address1>
<ns1:address2>Suite 123</ns1:address2>
<ns1:city>City</ns1:city>
<ns1:state>State</ns1:state>
<ns1:zipcode>12345</ns1:zipcode>
<ns1:country>FR</ns1:country>
<ns1:email>info@example.com</ns1:email>
<ns1:telephone>123 456 789</ns1:telephone>
<ns1:fax/>
</ns1:shippingaddress>
<ns1:billingaddress>
<ns1:company>Example Billing</ns1:company>
<ns1:attn>Person name</ns1:attn>
<ns1:address1>Street 1</ns1:address1>
<ns1:address2>Suite 123</ns1:address2>
<ns1:city>City</ns1:city>
<ns1:state/>
<ns1:zipcode>12345</ns1:zipcode>
<ns1:country>SE</ns1:country>
<ns1:email>info@example.com</ns1:email>
<ns1:telephone>123 456 789</ns1:telephone>
<ns1:fax/>
</ns1:billingaddress>
<ns1:internalinformation/>
<ns1:other>The buyer can leave a message or special instructions here.</ns1:other>
<ns1:ponumber>Example1</ns1:ponumber>
<ns1:market>
<ns1:id>Wholesale-Market</ns1:id>
<ns1:description>Global</ns1:description>
</ns1:market>
<ns1:pricelist>
<ns1:id>USD-Wholesale</ns1:id>
<ns1:description>US Dollar</ns1:description>
</ns1:pricelist>
</ns1:order>
</ns1:data>
</ns1:event>
</ns1:events>
</ns1:events_Get>
</SOAP-ENV:Body>
</SOAP-ENV:Envelope>Wholesale orders: Event Done#
https://docs.centra.com/soap/index.php?op=events_Done
This is exactly like the previous example for the direct-to-consumer order.
1
2
3
4
5
6
7
8
9
10
11
12
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<events_Done xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<event>121</event>
</events_Done>
</soap:Body>
</soap:Envelope>Wholesale orders: Confirm And Lock Order#
https://docs.centra.com/soap/index.php?op=orders_Update
Changes the order status from “pending” to “confirmed”, and locks the order so it cannot be modified in the Centra admin.
For wholesale orders it is common that the order has status “pending” when it is placed and then has to be confirmed (accepted) by someone working in Centra or on your side. If orders are confirmed in Centra, you should not import the order when it has status “pending”. Just mark that event as done. You will get a new event when it has status “confirmed”. In this example someone has confirmed the order on your side and this update marks it as confirmed in Centra.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<orders_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<orders>
<order>
<id>25</id>
<type>wholesale</type>
<store>2</store>
<status>confirmed</status>
<locked>yes</locked>
</order>
</orders>
</orders_Update>
</soap:Body>
</soap:Envelope>Wholesale orders: Cancel Item#
https://docs.centra.com/soap/index.php?op=orders_Update
Modifies the order by canceling a single size of a product from the order. I will cancel 1 of the 4 red sweaters in size L.
Notice the <orderitem> on the <size>. This is an unique ID for that row on the order, and you should always use it to modify the order. It is possible to have the same size twice or more in the same order, for example if one had a discounted price. The <orderitem> is always unique within the order, the <product> or <variation> or <size> is not.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<orders_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<orders>
<order>
<id>25</id>
<type>wholesale</type>
<store>2</store>
<cancelled>
<product>
<id>T001</id>
<variation>
<id>T001_RED</id>
</variation>
<sizes>
<size>
<id>L</id>
<qty>1</qty>
<orderitem>
<id>71</id>
</orderitem>
<supplierorderitems/>
</size>
</sizes>
</product>
</cancelled>
</order>
</orders>
</orders_Update>
</soap:Body>
</soap:Envelope>Wholesale orders: Shipment 1#
https://docs.centra.com/soap/index.php?op=orders_Update
Creates a shipment for some of the items in the order.
The <shipping> contains the shipping price, copied from the order event.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<orders_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<orders>
<order>
<id>25</id>
<type>wholesale</type>
<store>2</store>
<shipments>
<shipment>
<id>shipment-25-1</id>
<shipped>no</shipped>
<goodtogo>yes</goodtogo>
<appendix>1</appendix>
<products>
<product>
<id>T001</id>
<variation>
<id>T001_BLUE</id>
</variation>
<sizes>
<size>
<id>S</id>
<qty>1</qty>
<orderitem>
<id>68</id>
</orderitem>
</size>
<size>
<id>M</id>
<qty>1</qty>
<orderitem>
<id>69</id>
</orderitem>
</size>
</sizes>
</product>
<product>
<id>PWC</id>
<variation>
<id>PWC</id>
</variation>
<sizes>
<size>
<id>OS</id>
<qty>2</qty>
<orderitem>
<id>67</id>
</orderitem>
</size>
</sizes>
</product>
</products>
<shipping>
<subtotal>123</subtotal>
</shipping>
</shipment>
</shipments>
</order>
</orders>
</orders_Update>
</soap:Body>
</soap:Envelope>Wholesale orders: Shipment 2#
https://docs.centra.com/soap/index.php?op=orders_Update
Creates a shipment for the remaining items on the order.
Compared to the previous example, this one does not specify <shipping> so it will have 0 shipping cost.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<orders_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<orders>
<order>
<id>25</id>
<type>wholesale</type>
<store>2</store>
<shipments>
<shipment>
<id>shipment-25-2</id>
<shipped>no</shipped>
<goodtogo>yes</goodtogo>
<appendix>2</appendix>
<products>
<product>
<id>T001</id>
<variation>
<id>T001_BLUE</id>
</variation>
<sizes>
<size>
<id>M</id>
<qty>1</qty>
<orderitem>
<id>69</id>
</orderitem>
</size>
</sizes>
</product>
<product>
<id>T001</id>
<variation>
<id>T001_RED</id>
</variation>
<sizes>
<size>
<id>M</id>
<qty>3</qty>
<orderitem>
<id>70</id>
</orderitem>
</size>
<size>
<id>L</id>
<qty>3</qty>
<orderitem>
<id>71</id>
</orderitem>
</size>
</sizes>
</product>
</products>
<shipping>
<subtotal>0</subtotal>
</shipping>
</shipment>
</shipments>
</order>
</orders>
</orders_Update>
</soap:Body>
</soap:Envelope>Wholesale orders: Shipped#
https://docs.centra.com/soap/index.php?op=orders_Update
Marks both shipments as shipped.
Notice that the order is not seen as completed in Centra at this stage. It is seen as completed when it has been shipped and paid for.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>
<orders_Update xmlns="http://www.centra.com/webservices/">
<login>
<username>example</username>
<password>???</password>
</login>
<orders>
<order>
<id>25</id>
<type>wholesale</type>
<store>2</store>
<shipments>
<shipment>
<id>shipment-25-1</id>
<shipped>yes</shipped>
<carrierinformation>
<carrier>DHL</carrier>
<service>EXPRESS</service>
<tracking>876543210</tracking>
</carrierinformation>
</shipment>
<shipment>
<id>shipment-25-2</id>
<shipped>yes</shipped>
<carrierinformation>
<carrier>DHL</carrier>
<service>EXPRESS</service>
<tracking>987654321</tracking>
</carrierinformation>
</shipment>
</shipments>
</order>
</orders>
</orders_Update>
</soap:Body>
</soap:Envelope>
